GSM stands for Global System for Mobile Communications. It is the dominant mobile phone comminucation protocol in Europe and also popular elsewere. The name is also used to describe some of the voice codecs used in the GSM standards.

This page regards connecting a VoIP PBX to a GSM network, and connecting legacy PBX to either VoIP or GSM, or both. For more information about the codec, see the GSM codec/s.

GSM to H323 / SIP adapters

Hypermedia Systems

Connecting VoIP PBX to GSM

VoIP GSM Gateways

The VoIP GSM Gateway- HG-1600 series comes with 8 GSM VoIP ports for connecting IP-based systems with GSM networks. The VoIP GSM Gateway is designed to provide a cost-effective alternative for fixed-to-mobile or mobile-to-fixed telephone calls for small and medium businesses.



VoIP GSM Gateway HG-1600 main features:

• 4 - 8 GSM / VoIP ports
• Up to 32 SIM cards
• Advanced LCR and routing groups
• IP address and DDI pattern restrictions
• Remote pre-paid SIM recharge
• Integrated antenna splitter
• GSM worldwide use
• WEB management and control

Additional VoIP Gateways for connecting IP-based systems with Cellular networks.

Connecting Legacy PBX to VoIP and GSM

GSM Gateways

The ISDN GSM GatewayHG-2000 series of PRI Cellular Gateway products are equipped with PRI interface and start with 12 Cellular channels.



The E1/T1 PRI GSM Gateway supports up 32 cellular ports, and provides superior voice technology for connecting PBX systems and IP-based systems with the cellular networks. The HG-3000 Series of PRI Cellular Gateways enable inbound and outbound calls over GSM, CDMA and PSTN networks, with optional support of VoIP calls.

Further range of GSM Gateways for routing incoming and outgoing calls via the mobile telephone network.

Connecting PBX to VoIP, Cellular and Fixed networks

Mobility Extension (mobex)

The Mobility Extension Gateway is a stand-alone PBX add-on system that provides companies with a business-class enterprise mobility solution, enabling employees to work from everywhere and anywhere, yet enables enterprises to retain control over phone numbers and other calling policies.

This latest Mobility Extension feature provides easy integration of IP technology with the legacy telephony environment, and connects mobile phones and other external telephony devices to the PBX as "virtual" PBX extensions, and enables remote access to the enterprise's PBX/IP PBX regardless of employee's whereabouts or telephony device (Cellular phone, WiFi phone, Multi-radio Smartphone, laptop, or any VoIP device).

Other related products:

• 3G VoIP Gateway
• 3G UMTS Analog Gateway
• GSM Analog Gateway
• PRI 3G UMTS Gateway

FOR MORE INFORMATION:

http://www.hyperms.com
mailto:Info@hyperms.com

PORTech VoIP GSM Gateway,Follow Me GSM Gateway/GSM Fixed Wireless Terminal,E1 GSM Channel Bank,Skype GSM Gateway

PORTech is a manufacturer in taiwan. PORTech major in 1,4,8 ports GSM Fixed Wireless Terminals(follow me),1,2 ports VoIP GSM Gateway,E1 GSM Channel Bank,Skype GSM gateway and Remote power manage by PSTN and WEB
http://www.portech.com.tw

MV-370 : 1 channel VoIP GSM Gateway

MV-372 : 2 channels VoIP GSM Gateway

for call termination (VoIP to GSM ) and origination (GSM to VoIP). It is SIP based and compatible with Asterisk. It can enable to make 2 calls simultaneously from IP phones to GSM networks and GSM network to IP phone.
We support one stage dialing and two stage dialing.
One stage dialing:You can dial any mobile number from your lan phone directly.MV-370/MV-372 will connect the call.
Two stage dialing:when you call in MV-370,you will hear dial tone and you can dial any ip,asterisk extension or phone number.
GSM Frequency :Dual band:900/1800MHZ,Tri band:900/1800/1900MHZ,Tri band:850/1800/1900MHZ,

MT-350~1 ports GSM Fixed Wireless Terminals,Follow Me GSM Gateway

MT-350S:1 port SMS GSM Gateway
MT-354~4 ports GSM Fixed Wireless Terminals,Follow Me GSM Gateway
MT-358~8 ports GSM Fixed Wireless Terminals,Follow Me GSM Gateway
MT-358_Follow Me GSM Gateway
Cost saving effect- Make call from fixed lines (PBX or PSTN) to GSM networks
and From GSM network to fixed lines), and enables up to 1/4/8 simultaneous calls to/from GSM networks.
1.FXS,FXO,GSM interface.
2.Dial plan (GSM Prefix No.Setting (50 sets))
3.Auto-select economic route ( LCR )
4.Only 1 (MT-350,MT-354) or 2(MT-358) antennas
5.Polarity reversing function
6.Follow me-Call-transfer feature (GSM TO PSTN,PSTN TO GSM)
-PSTN to GSM:
 An incoming call of PSTN will be transferred to specify GSM no.
- GSM to PSTN:
 1. GSM in PSTN out, give you a prompt "du" and you can enter any
     destination number 　
 2.An incoming call of GSM will be transferred to specify PSTN no.
GSM Frequency :Dual band:900/1800MHZ,Tri band:850/1800/1900MHZ,

Digital Mobile Trunk (DMT) ~E1 GSM Channel Bank
DMT accepts incoming call from E1/T1 PRI of PSTN or
PBX and choose one GSM channel to dial out according to the prefix of the
destination mobile number. In this way, we can have least cost routing.
DMT can provide Call Detail Record (CDR) for traffic and accounting management.
ISDN PRI interface: 1 port
GSM interface: 31 ports
Optional external SCE-900: Expands SIM card upto 32 pieces per GSM channel.
Optional external SCBox: Expands SIM card upto 4 pieces per GSM channel.
Applicable for telecom service providers
VoIP application: Gateway's E1/T1 port connects DMT's E1/T1 port
Calling time: user can assign the calling time for each sheet of the SIM
card.When the time runs out, system will block this GSM port, or switch
to next unused SIM card (in the case that SCE is installed).
Besides PRI to GSM,you may also apply GSM to PRI (two ways).
Additionally,we also develop DMT-2 that is E1*1 in,GSM*31 and E1*1 out.
GSM Frequency :Dual band:900/1800MHZ,Tri band:900/1800/1900MHZ,Tri band:850/1800/1900MHZ

DMT-E1 GSM Channel Bank

Antenna collecting Box: Base equipment.


If you want to connect extra Outdoor directional antenna or Yigi antenna.....,you can purchase option Antenna Combiner(AC-32)


If your control room is usually no body there,you can consider our Smart Power Monitor(4 ports)- Remote power on/ off /reboot by PSTN and WEB..



SkyTrunk: Skype to PBX free, PBX to Skype free

SkyTrunk ST-1004~4 ports skype,FXO,FXS,GSM
GSM Frequency :Dual band:900/1800MHZ,Tri band:900/1800/1900MHZ


SkyTrunk ST-2004 ~4 ports Skype,FXS


SkyTrunk ST-3004~4 ports skype,FXO,FXS


SkyServer:~4 ports Skype,FXS (Build in pc)


If you have interest,please contact us

Rebecca Liu
PORTech Communications Inc.
150 Shiang Shung N.Rd,Taichung,Taiwan
http://www.portech.com.tw
E-mail:info@portech.com.tw
http://www.portech.com.tw/eweb/PORTECH_dm.pdf ---- PORTech Products list
