Grandstream GXP1100

Grandstream GXP1100 IP Phone

GXP1100 is a next generation small business IP Phone that features up to 2 call appearances with 1 SIP account, 3 programmable keys, single network port. The GXP1100 delivers superior HD Audio quality, leading edge telephony features, automated provisioning for easy deployment, advanced security protection for privacy, and broad interoperability with mose 3rd party SIP devices and leading SIP / NGN / IMS platforms. It is a perfect choice for small business, lobby, and hotel applications looking for a high quality, basic IP Phone with attractive cost.

Feature Highlights

• Single SIP account and up to 2 call appearances, 4 programmable keys
• HD handset with support for wideband audio
• 7 dedicated function keys for Hold, Flash/Call-Waiting, Transfer, Message, Mute, Volume, Dial / Redial
• Automated provisioning using TR-069 or AES encrypted XML configuration file, SRTP and TLS for advanced security protection, 802.1x for media access control.

Telephony Features

• Hold
• transfer
• forward
• 3-way conference (via programmable key)
• Call waiting
• Off-hook auto dial
• Click-to-dial
• Flexible dial plan
• Hot-desking
• Personalized music ringtones
• Server redundancy and fail-over.

Protocols / Standards

• SIP RFC3261
• TCP/IP/UDP
• RTP
• HTTP/HTTPS
• ARP/RARP
• ICMP
• DNS (A record, SRV, NAPTR)
• DHCP
• PPPoE
• TELNET
• TFTP
• NTP
• STUN
• TR-069
• 802.1x

Network Interfaces

• Single 10/100Mbps port

Feature Keys

• 1 SIP account
• 4 programmable keys
• 7 dedicated function keys for: Hold, flash, transfer,mute, volume, redial and message (with LED indicator)

Voice Codec

• Support for G.723.1
• G.729A/B
• G.711 µ/a
• G.726-32
• G.722 (wide-band)
• iLBC
• In-band and out-of-band DTMF (in audio, RFC2833, SIP INFO)

HD Audio

• HD handset with support for wideband audio

Headset Jack

• N/A

Base Stand

• 1 angle position available

Wall mountable

• Yes

QoS

• Layer 2 (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS

Security

• User and administrator level passwords
• MD5 and MD5-sess based authentication
• AES encrypted configuration file
• SRTP
• TLS
• 802.1x media access control

Languages

• English
• German
• Italian
• French
• Spanish
• Portuguese
• Russian
• Croatian
• simplified and traditional Chinese
• Korean
• Japanese and etc supported in web configuration interface.

Upgrade / Provisioning

• Firmware upgrade via TFTP/HTTP/HTTPS
• mass provisioning using TR069 or AES encrypted XML configuration file.

Power and Green Energy Efficiency

• Universal power adapter included
• Input: 100-240VAC 50-60Hz
• Output: +5VDC, 800mA
• Typical power consumption under 1W (power adapter) or under 1.5W (PoE)

Physical

• Unit dimension: 201mm (W) x 154mm (L) x 78mm (D)
• Unit weight: 0.6kg
• Package Weight: 1.0kg (GXP1100)

Operating Temperature & Humidity

• 32-104 °F / 0-40 °C, 10-90% (non-condensing)

Package Content

• GXP1100 phone
• handset with cord
• base stand
• universal power supply,
• network cable
• quick start guide

Compliance

• FCC Part 15 (CFR 47) Class B
• EN55022 Class B
• EN55024
• EN61000-3-2
• EN61000-3-3
• EN60950-1
• AS/NZS CISPR 22 Class B
• AS/NZS CISPR 24
• RoHS
• UL 60950 (power adapter)
