IP PBX For SMB

PBX Features

BLF (Busy Lamp Field)
DID (Direct Inward Dialing Number)
Conference Room(3)
Automated Attendant
IVR (Interactive Voice Responses)
DISA (Direct Inward System Access)
CDR (Call Detailed Record)
Voicemail
Feature Codes
SIP Trunk (10)
Blacklist
Phone Book
IP Phone Provisioning
Multiple Language (Chinese / English /
Portuguese)
Support Skype for SIP
T.38 FAX(Pass-through)
Trouble Shooting (Ping, Traceroute)

Call Features

Caller ID
Video Calls
Call Paging and Intercom
Call Forward
Call Pickup
Call Park
Call Group
Call Routing
Music on Hold / Transfer
Call Transfer
Call Hold
Call Waiting
Call Queue
Call Recording
Three-Way Conference

System Capacity

30 IP Phone Users
256 MB Onboard Flash
Recording(GSM): 2100 min
Voicemail(GSM): 2000 min

Codec & Protocol

Audio Codec:
G.711(a-law, u-law),G.729,G.726,
GSM,Speex
Video Codec Pass-through:
H.261,H.263,H.263+,H.264
Protocol: SIP (RFC3261) , IAX2
DTMF: RFC2833, SIP INFO, In-band

Network Features

DHCP Server
IP Assignment (DHCP / Static)
VPN Client (Support N2N / L2TP)
Network Address Translation (NAT)
DDNS Client (Support Dyndns.org /
No-ip.com)
Support PoE

Hardware Specifications

1 WAN Port
1 Power Adapter Port
1 Reset Button
2 Analog Ports
LED indication
Power Supply:
Input: 100 V ~ 240 VAC
Output: DC 12 VDC, 2.0 A

Environmental Specifications

Temperature: -10 °C-45 °C
Storage temperature:-30 °C-65 °C
Humidity: 10-80% no dew
